Solutions for Indian Hydrocarbon Industry

First-Class, Competent, and Tailor-Made Solutions for Indian Hydrocarbon Industry RMA
RMA Measuring and Control Technology has evolved over the years as a leading manufacturer of Gas
Ultrasonic flowmeters at their German facility and sold successfully
worldwide. RMA also operates its own high-pressure gas calibration facility and caters to customers and
OEM looking for a state-approved calibration facility. RMA has now partnered with Eximp MeasurementPrivate Limited (EMPL) to offer the Indian subcontinent their first-class, competent, and tailor-made
solutions.

RMA core offerings:
– ECOSONIC X12 Ultrasonic Gas Meter
Highly precise and robust measuring instruments used for flow measurement of gases. ECOSONIC
X12 uses six independent measuring paths and even if a measuring path fails, it can still carry custody
transfer measurement.
Advantages:
No pressure losses
Large measuring ranges (up to 1:120)
No moving parts, no wear, and tear, maintenance-free
Electronic processing of the measured values
Very precise measuring results by using flow correction methods
– High-Pressure Test Facility
State-approved test center for gas meters with closed Loop.
Measure following devices and verified with our test facilities:
Volumetric gas meters
Rotary displacement meters
Velocity gas meters
Ultrasonic flowmeters
Vortex flowmeters
Turbine meters
Gas volume (PTZ) correctors and additional equipment
Facts:
Testing with natural gas under real conditions Closed-loop system independent of
Daily gas consumption
Weather
Consumption
All pressure ranges and all flow rates of the measuring range are fully adjustable Constant gas quality
Two parallel meter runs of more than 12 m each
All flange sizes from PN 10 up to ANSI 600
Pressure: 1 bar absolute up to 51 bar absolute
Flow rate: 3 m3/h up to 13,000 m3/h
Nominal diameter of the specimen: from DN50 up to DN 500
Working standards- 2 x G 4000 Turbine gas meter
G 650 Turbine gas meter
G 100 Rotary displacement gas meter

Key Features:
– Testing with natural gas under real conditions.
– Closed-loop system.
– All pressure ranges and all flow rates of the measuring range are fully adjustable.
– Constant gas quality is able to carry out the custody transfer measurement.
– Pressure: 1 bar absolute up to 51 bar absolute.

Application Areas:
It can be used in the following industrial sectors:
Gas Transportation | Storage | Distribution | Industrial Use
